Shelly FrankEver Smart Wi-Fi 6-Channel Irrigation Controller (FK-06X)

The Shelly - FrankEver Sprinkler Controller FK‑06X is a 6-zone Wi‑Fi/Bluetooth-based irrigation controller, making it an excellent choice for automating watering in gardens, greenhouses, or smaller agricultural areas. Each zone can be independently controlled, allowing for personalized schedules and water supply settings, which makes it ideal for managing various plant zones. It operates without the need for a central hub, working standalone via the Shelly Smart Control app or web interface, and it can also be manually controlled with built-in buttons.

One of the device’s key advantages is the integrated weather API, which automatically adjusts the watering schedule in case of rain or heatwaves. This not only saves water but also makes the system truly smart. The 24 V AC outputs allow for standard solenoid valve control, ensuring easy installation and broad compatibility.

This premium Plug&Play product is built on the ShellyX platform, ensuring reliable operation, local and cloud-based control, and Bluetooth relay functionality. Thanks to its compatibility with Home Assistant and MQTT, it's also an ideal solution for DIY enthusiasts.

About the Shelly Brand

Shelly is the smart home brand of the Bulgarian Allterco Group, internationally recognized for its innovative, reliable, and broadly compatible smart devices. Its product portfolio includes relays, sensors, energy monitors, and smart lighting solutions. Shelly devices are compatible with leading platforms such as Google Home, Amazon Alexa, Home Assistant, and SmartThings, and their open protocols make integration with other systems simple and flexible.

Main Product Features

• Independent control of 6 zones – customizable zone names, operating times, and flow rates
• 24 V AC outputs – supports standard solenoid valves
• Wi‑Fi & Bluetooth – works without a hub, also usable as a Bluetooth relay
• Weather API – automatically adapts to weather conditions
• Local and cloud control – via Shelly Cloud, WebUI, and mobile app
• Physical buttons and LED display – manual control and status indication

Smart Home Protocols and Platform Compatibility

• Protocols: Wi‑Fi 802.11 b/g/n, Bluetooth – multi-protocol operation, hub-free usage
• Local control: Bluetooth relay function – for quick local commands and signal boosting
• Native platform: Shelly Smart Control App and web interface
• Cloud integration: Google Home, Amazon Alexa
• Third-party platforms: Home Assistant, MQTT support
• Voice control: supported (Alexa, Google Assistant)

Smart Features

• Remote zone control – ON/OFF and start/stop via the app
• Automated weather-based irrigation – adjusts scheduling based on rain or heat detection
• Cycle mode – customizable zone sequences and cycle times
• Rain delay – options for 24/48/72 hours
• Local and cloud logging – event and watering data recording
• Automation options – Home Assistant compatibility with soil moisture sensors

Electrical Specifications

• Power input: 230 V AC, 24 V AC outputs
• Zone outputs: 6 × 24 V AC for solenoid valves
• Power monitoring: not supported
• Switch input: built-in physical buttons
• Timer relay function: automatic weather-based delay
• Dry contact switching: not supported

Other Specifications

• Warranty: 2 years
• IP rating: IP20, recommended for indoor use
• Plug&Play: easy installation, no expertise required
• Operation: hybrid – local and cloud-based control
