frient Water Leak Detector – Water leakage sensor with thermometer and 85dB audible alarm, Zigbee (FLSZB-110)

The frient Water Leak Detector (FLSZB-110) is a Zigbee 3.0 battery-powered water leak sensor with a built-in 85 dB audible alarm and temperature sensor.

The contacts on the bottom of the device can detect even a small amount of water. When a leak is detected, the device activates a local audible alarm and reports the event to the connected Zigbee system. The smart home platform in use can then send a mobile notification or trigger an automation.

The sensor can be placed on the floor near a washing machine, dishwasher, boiler, sink, water pipe, or other equipment where leaks may occur. For hard-to-reach areas, an optional Water Leak Detector Probe with a 90 cm cable can be connected. In this setup, the main sensor can be mounted on the wall, while the separate sensing head is placed in the monitored area.

The device is powered by one replaceable CR123A lithium battery. According to the manufacturer, the expected battery life is approximately five years with normal reporting every five minutes. The built-in temperature sensor measures between 0 and +50 °C, while the water alarm status is reported immediately.

About frient

frient is a Denmark-based company that develops and manufactures Zigbee-based smart home devices. Its product range includes door and window sensors, motion sensors, temperature and humidity sensors, air quality sensors, water leak detectors, vibration sensors, smoke and heat alarms, smart plugs, energy meters, and other smart home accessories.

frient products use the standard Zigbee 3.0 protocol, making them compatible with a wide range of Zigbee gateways. They are supported by Home Assistant, Zigbee2MQTT, ZHA, SmartThings, Homey, and many other Zigbee-based systems. Available features may vary depending on the gateway and its device support.

Key Product Features

• Water leak detection: The contacts on the bottom of the device detect water present on the surface.
• Immediate alarm: When a leak is detected, the device immediately sends an alarm state to the Zigbee hub.
• Built-in audible alarm: The local siren produces a sound pressure level of 85 dB at a distance of 3 metres.
• Temperature measurement: The integrated sensor measures ambient temperature between 0 and +50 °C.
• Remote notification: The connected smart home system can send a mobile notification when a water alarm event occurs.
• Automation event: A leak alarm can be used to control a motorised water shut-off valve, siren, lighting, or other devices.
• Tamper indication: In supported integrations, movement of the device or handling of the enclosure may appear as a separate status.
• Optional sensor probe: A separate probe with a 90 cm cable can be used to monitor hard-to-reach areas.
• Replaceable battery: Operates with one CR123A lithium battery.

Smart Home Protocols and Platform Compatibility

• Zigbee 3.0: Uses low-power wireless communication. A compatible Zigbee gateway or coordinator is required.
• Zigbee end device: Connects to the network as a battery-powered end device and sends its own sensor data to the coordinator.
• Home Assistant: Can be used in a local system with a compatible Zigbee adapter.
• Zigbee2MQTT: Supported as model FLSZB-110. Water alarm, temperature, battery level, battery voltage, low battery status, and tamper status are available.
• MQTT integration: When Zigbee2MQTT is used, sensor and status data can be transmitted as MQTT messages.
• ZHA: Can be connected to a local system through the Home Assistant Zigbee Home Automation integration.
• Samsung SmartThings: Can be used with a compatible SmartThings Zigbee hub. Availability of water alarm, temperature, and battery status depends on the device handler being used.
• Homey: Can be used in water leak and temperature automations through the frient integration.
• Local operation: When used with Home Assistant, Zigbee2MQTT, or ZHA and a local Zigbee coordinator, sensor data can be processed on the local network.

Smart Features

• Water alarm status: The system displays whether the sensor is dry or detecting a leak.
• Push notification: The selected platform can send a notification when water is detected.
• Alarm automation: In the event of a leak, a motorised water shut-off valve, compatible siren, relay, or other device can be controlled.
• Temperature display: The measured ambient temperature can be displayed and logged.
• Temperature-based automation: The measured value can be used as a condition for frost protection or room-temperature automations.
• Temperature calibration: In Zigbee2MQTT, software correction of the measured temperature can be configured.
• Battery level: Supported systems can display the remaining battery capacity as a percentage.
• Battery voltage: When Zigbee2MQTT is used, the current battery voltage is also available in millivolts.
• Low battery status: The need for battery replacement can be used as a separate condition for notifications.
• Tamper status: In supported integrations, movement of the sensor can be handled as an automation event.
• OTA firmware update: Wireless firmware updates are supported through Zigbee2MQTT.

Technical Specifications

• Product name: Water Leak Detector
• Model: FLSZB-110
• Product type: Zigbee water leak detector
• Wireless protocol: Zigbee 3.0
• Zigbee device type: End device
• Power supply: 1 × replaceable CR123A lithium battery
• Expected battery life: Approximately 5 years with reporting every 5 minutes
• Battery monitoring: Battery level and low battery reporting
• Receiver sensitivity: -92 dBm
• Radio transmit power: Typically +4 dBm
• Wireless range: At least 100 m in open space
• Siren output: 85 dB at 3 m
• Normal reporting interval: 5 minutes
• Alarm reporting: Immediate
• Temperature measurement range: 0 to +50 °C
• Temperature resolution: 0.1 °C
• Temperature accuracy: ±0.5 °C
• Protection rating: IP20
• Operating temperature: 0 °C to +50 °C
• Operating humidity: Up to 95% RH, non-condensing
• Dimensions: Ø 60 × 37 mm
• Colour: White
• Compliance: CE, FCC, RoHS, and REACH

Optional Water Leak Detector Probe

• Purpose: Designed for detecting water leaks in hard-to-reach, narrow, or low-lying areas.
• Installation: The main sensor can be placed in the probe holder and mounted on the wall, while the separate sensing plate remains on the floor.
• Cable length: 900 mm
• Probe dimensions: Ø 50 × 8.5 mm
• Colour: White

Additional Features

• Placement: Can be placed on a flat floor surface where leaking water is expected to collect or flow.
• Recommended locations: Suitable for use near washing machines, dishwashers, boilers, water heaters, sink cabinets, pipe connections, basements, or mechanical equipment.
• Sensing surface: The bottom contacts must be in direct contact with the monitored surface.
• Post-installation test: After installation or battery replacement, the local audible alarm should be tested using the device’s test button.
• Communication environment: Metal equipment enclosures, reinforced concrete structures, and long distances may reduce Zigbee communication range.
• Zigbee network extension: Installing a mains-powered Zigbee router can improve communication between the sensor and the coordinator.
• Platform-dependent features: Availability of tamper reporting, battery voltage, temperature calibration, and OTA updates depends on the Zigbee integration being used.
